Description
Technical dataOutput voltage at 1000 Hz, 5cm/sec: 2 mVChannel balance at 1 kHz: < 2 dBChannel separation at 1 kHz: > 25 dBChannel separation at 15 kHz: > 15 dBFrequency range at – 3dB: 20-45.000 HzFrequency response FIM distortion at recommended: 20-20.000 Hz +3 /-1.5 dBTracking ability at 315Hz at recommended Tracking force *: > 60 ﾵmCompliance, dynamic, lateral: 13 ﾵm/mNStylus Type: Nude FG 70Stylus tip radius: r/R 5/70 ﾵmTracking force range: 1.8-2.2 g (18-22 mN)Tracking force, recommended: 2 g (20 mN)Tracking angle: 20ﾺInternal impedance, DC resistance: 80 ΩRecommended load impedance: 47 kΩ / < 500 pFCartridge body material: NorylCartridge colour: RedCartridge weight: 4.1 g* Typical value
