Description
Technical data Ortofon 540 Original replacement stylus Frequency range: 20-27,000 Hz Frequency response: 20-20,000 Hz + 2 / – 3 dB Channel separation: 25 dB Tracking ability at 315 Hz at recommended Tracking force*: 90µm Compliance, dynamic, lateral: 30µm/mN Stylus Type: Nude Fritz Gyger II Nude Stylus tip radius: r/R 8/40µm Equivalent stylus tip mass: 0.3mg Tracking force range: 1.0-1.5g (10-15mN) Tracking force, recommended: 1.5g (15mN) Tracking angle: 20º Stylus colour: Black Recommended for the following cartridges 540 MkII, 540, 540P and all other 500 Series Typical value*. Any questions Contact Us
