Concorde PRO S Cartridge

£90.00

SKU: O-CONPROS Category:

Description

The Pro-S retains the overall sonic properties of the Pro Silver, but provides a wider stylus for low wear as well as durability under demanding conditions.

No matter what the application, the Pro-S provides remarkable versatility for virtually any setting.

Technical data:
Model Type: Moving Magnet Complete Uni Headshell and Stylus
Output Voltage at 1000 Hz, 5cm/sec: 5mV
Channel Balance at 1 kHz: 2dB
Channel Separation at 1 kHz: 20dB
Channel Separation at 15 kHz: 15dB
Frequency Range at -3dB: 20-20,000Hz
Frequency Response: 20-18.000 Hz +3/-2dB
FIM Distortion at Recommended force: DIN 45.542 <1%
Tracking ability at 315Hz at recommended Tracking force: 70µm
Compliance, Dynamic, Lateral: 7µm/mN
Stylus Type: Spherical
Stylus tip radius: R 18µm
Tracking force Range: 3.0-5.0g (30-50 mN)
Tracking force: Recommended 4.0g (40mN)
Tracking Angle: 20º
Internal Impedance: DC resistance 750Ω
Internal Inductance: 450mH
Recommended Load Resistance: 47kΩ
Recommended Load Capacitance: 200-600pF
Cartridge Colour: Body/Stylus Black/Black
Cartridge weight: 18.5g
Original Replacement Stylus: STYPRO S
